LM1RP Vacuum lifter with 1 suction pad

Suitable for handling small sized materials

PNEUMATIC VACUUM LIFTER FOR MARBLE SLABS

  • Structure with 0°-90° pneumatic tilting which allows to work more easily;
  • Continuous vacuum pump powered by compressed air;
  • Vacuum gauge with graduated and coloured scale to more easily monitor the degree of vacuum;
  • Powerful and quiet vacuum generator with reduced air consumption of 100 lt/min;
  • Operating pressure 4/6 Bar;
  • Gaskets made of rubberized fabric and mousse suitable for smooth, flammed and bush-hammered surfaces;
  • High-limit yielding steel suction pads made of first quality materials;
  • No-falling non-return valve for vacuum;
  • Sliding valve to control gripping and releasing of the material with safety block against involuntary manoeuvres;
  • Ample safety tank in aluminium for vacuum reserve, to guarantee gripping even when there is a power cut and with condensation discharge valve;
  • Acoustic and visual alarm system which automatically signals a low vacuum degree. It works autonomously by means of rechargeable batteries and it is supplied with the appropriate battery charger at 220 volt;

Technical data sheet

TypeLM1RP
Capacity801001252002502503003005005001000


Suction cup

1
C4004005006005007006008005508001000
D150200200200300200300200400300450
M400400400400400400400400450450500
H880880880880880880880880900900900
